Santa Fe Impact155 Dehumidifier

• Model: Impact155
• Part Number: 4031470
• Water Removal: 155 Pints/Day
• Supply Voltage: 115 volt - 1 phase - 60 Hz
• Operating Temperature: 49°F Min., 95°F Max.
• Weight: 140 lbs.

Horizontal configuration. Dual outlet design. Quiet operation. What more can you want from a dehumidifier?

The Impact155 is made to handle larger basements, garages and crawl spaces efficiently. Simply put, no job is too big for this powerful yet efficient unit.

The Impact155 is the perfect solution for controlling humidity in large basements and crawl spaces. Featuring patented heat exchanger technology to remove more water using less energy, its’ dual airflow outlets provide maximum space drying and installation flexibility.

Click here to view more of Santa Fe Dehumidifiers

• Dual exhaust outlets allow for air distribution to multiple locations
• Horizontal solution is great for larger basement or crawl space applications
• Engineered for low temperature operation and the air flow issues that crawl spaces and basements present
• Ducting options for divided spaces
• Auto restart allows the dehumidifier to automatically restart after a power outage

Water Removal Rates(Pints/Day)

• @ 80°F and 60%RH - 155 Pints / 19.375 Gallons
• @ 65°F and 60%RH - 104 Pints / 13 Gallons

• Model: 4031470

PERFORMANCE

• Water Removal:
• @ 80°F and 60%RH - 155 Pints / 19.375 Gallons
• @ 65°F and 60%RH - 104 Pints / 13 Gallons
• Efficiency:
• 7.3 Pints/kWh
• 4.2 Pints/kWh
• Energy Factor:
• 3.4 L/kWh
• 2.0 L/kWh
• Blower: 391 CFM @ 0.0” WG
• Operating Temperature: 49°F Min., 95°F Max.
• Crawl Space Sizing: 3,600-4,400 Sq. Ft. / 18,000-22,000 Cu. Ft
• Basement Sizing: 3,600-4,000 Sq. Ft. / 36,000-40,000 Cu. Ft.

ELECTRICAL

• Power Cord: 9', 115 VAC, Ground Plug Type B (USA, MEX, CAN, JPN)
• Power: 920 watts @ 80°F and 60% RH
• Supply Voltage: 115 volt – 1 phase – 60 Hz
• Current Draw: 8.0 amps

SPECIFICATIONS

• Drain Connection: 3/4" Threaded Female NPT
• Drain Hose: 8' Direct Gravity Drain Hose (5/8" ID x 7/8" OD)
• Refrigerant: R410A, , 2 lbs. 1 oz.

UNIT DIMENSIONS

• Width: 20.25"
• Height: 21.75"
• Depth: 38"
• Weight: 140 lbs

SHIPPING

• Shipping Dimensions: 25"W x 28"H x 42"D
• Shipping Weight: 159 lbs.
• Pallet Quantity: 1 per pallet
• Shipping Options: UPS and LTL
